CDD-562AL/564A/L Multi-Channel Demodulator Revision 0
Introduction MN-CDD562AL/564AL
1–5
1.3 Features
1.3.1 Physical Description
The demodulator is a 1RU-high chassis. You can install it into a rack or as a free standing unit. Handles at
the front help with rack installation.
1.3.2 Major Assemblies
Model Assembly Description
CDD-564AL
PL-0021662 AC Chassis
PL-0021314 DC Chassis
PL-0021861 Quad Demodulator Card
PL-0021412 0.95 Turbo Product Codec Card, optional
CDD-564A
PL-0021666 AC Chassis, IF
PL-0021715 DC Chassis, IF
PL-0021660 Quad Demodulator Card
PL-0021412 0.95 Turbo Product Codec Card, optional
CDD-562AL
PL-0022006 AC Chassis
PL-0022045 DC Chassis
PL-0021863 Dual Demodulator Card
1.3.3 Interoperability/Compatibility
The demodulator works with the Comtech EF Data Satellite Modems that have the optional IP
Module/router:
• CDM-570/L-IP
• CDM-570A/L-IP
The demodulator supports the receive functions of the equipment.
