PCB-4000 1+1 Phase Combiner Revision 2

Appendix A MN/PCB4000.IOM

A–16

A.3.2 PCB-4000 C-Band Unit (PL-0000330) Assemblies

A.3.2.1 C-Band 1+1 Phase Combined Top Assem

bly Kit – HPOD (KT-0000055)

Table A-8. Kit KT-0000055 BOM

Kit KT-0000055 (see Figure A-7)

Item No. QTY CEFD Part No. Description

1 1 KT-0000017 1:2 Unistrut Mounting Kit

2 2 KT/12300-1 HPOD Mounting Bracket Kit

3 1 KT-0000056 C-Band Phase Combiner Box and Bracket Kit

4 1 KT-0000054 C-Band 1:1 HPOD Waveguide and Switch Kit

N/A 2 CA/RF11872-1* Cable Assembly, Ku-Band RF IN

N/A 2 CA/WR11966-1* Cable Assembly, SSPA to Combiner Box

N/A 1 CA/WR12013-1* Cable Assembly, Switches, Combined System

N/A A/R HW/TW14.5HDBLK Cable Ties

Notes:

1. A/R=AsRequired

2. *SeeChapter3.INSTALLATION,STARTUP,andTROUBLESHOOTINGPROCEDURESforinformationonmakingcableconnections

ina1+1PhaseCombinerSystem.
