PCB-4000 1+1 Phase Combiner Revision 2

Updating Firmware MN/PCB4000.IOM

4–3

C. Energize thePCB‐40001+1PhaseCombinerSystem(thePCB‐4000derivesitspowerfrom

theSSPAs).



3. ObtainthefirmwarenumberforthePCB‐4000.



OnthePC:Viaserialremotecontrol,obtainthefirmwarenumberbyusingthe<0/FRW?query.



SeeChapter5.SERIALREMOTECONTROLforinformationandinstructions

onusingremotecommandsandqueriesviathePCB‐4000SerialInterface. 

4. Createatemporaryfolder(subdirectory)ontheuserPCforthefirmwarearchivedownload.



• Driveletter“c:”isusedintheseexamples.Anyvalid,writabledriveletter

canbeused.



• Typicalforalltasks:Typethecommandwithoutquotes

,andthenpress

Entertoexecute.



ThereareseveralwaysyoumayusecreateatemporaryfolderonaWindows‐basedPC:



A. UsetheWindowsDesktoptocreateandrenamethetemporaryfolder.



• Right‐click anywhere on the desktop to open the popup submenu,and then select

New>Foldertocreatethetemporaryfolder.Thene

wfolderwillbecreatedonthe

desktop.



• Right‐clickonthe newfolderand thenselect“Rename”fromthepopupsubmenu.

Renamethisfolderto"temp"orsomeotherconvenient,unused name.



B. UseWindowsEx

plorertocreateandrenamethetemporaryfolder.



• Select File > New > Folder to create the temporary folder. The new folder  will be

createdintheactivefolder.


