PCB-4000 1+1 Phase Combiner Revision 2

Appendix A MN/PCB4000.IOM

A–8

A.2.3 HPOD Mounting Bracket Kit (KT/12300-1)

Table A-4. Kit KT/12300-1 BOM

HPOD Mounting Bracket Kit KT/12300-1 (as per Figure A-3 on next page)

Item No.

QTY CEFD Part No. Description

1 2 FP/BR12239-1 Bracket, Unistrut

2 4 HW/3/8SPRINGNUT

Spring Nut, 3/8-16, Short Spring, SS

(P3300)

3 4 HW/3/8-FLT Washer, Flat, 3/8

4 4 HW/3/8-SPLIT Washer, Lock, Split, 3/8, SS

5 4 HW/3/8-16X1BLT Bolt, Hex Head, 3/8-16 x 1” LG, SS

6 4 HW/5/16-18HEXNT Nut, Hex, 5/16-18, SS

7 8 HW/5/16-Flat Washer, Flat, 5/16, SS

8 4 HW/5/16-SPLIT Washer, Lock, Split, 5/16, SS

9 4 HW/5/16-18X1BLT Bolt, Hex Head, 5/16-18 x 1” LG, SS
