PCB-4000 1+1 Phase Combiner Revision 2

Appendix A MN/PCB4000.IOM

A–6

A.2.2 Unistrut Mounting Kit (KT-0000017)

Table A-3. Kit KT-0000017 BOM

Unistrut Mounting Kit KT-0000017 (as per Figure A-2 on next page)

Item

No.

QTY CEFD Part No. Description

1 3 FP-0000134 Unistrut, Dual Channel, 74.13” LG

2 4 FP/BR11932-1 Bracket, Unistrut, SS, 26.25” LG

4 12 HW/3/8SPRINGNUT

Spring Nut, 3/8-16, Short Spring, SS

(P3300)

5 12 HW-0000069 Washer, Flat, Thick, 3/8, SS

6 12 HW/3/8-SPLIT Washer, Lock, Split, 3/8, SS

7 12 HW./3/8-16X1BLT Bolt, Hex Head, 3/8 x 1” LG, SS
