SDM-2020 Satellite Demodulator Revision 4

Front Panel Operation MN/SDM2020D.IOM

6–22

Function Select: Configuration: Interface: Buffer Center

(Conditional)

Buffer Center

Yes/No

This configuration function is used to center the buffer. Choosing YES centers the buffer.

IMPORTANT

Available with G.703 interface. This requires that the optional Overhead

card is installed.

On entry, the current position of the buffer is displayed. Press [↑] or [↓] to change the

format. Press <ENTER> to execute the change.

6.1.5.4 Function Select: Configuration: Save

CONFIGURATION XX

SAVE

The Configuration Save (XX = 1 through 10) menu allows the user to program

configuration parameters into non-volatile memory on the M&C. There are 10 memory

locations that may be used to store specific frequently used configuration setups.

After changing the configuration parameters to the desired settings, enter the

Configuration Save menu and select memory location 1 through 10 by pressing

[↑] or [↓].

Press <ENTER> to execute the save.
