SDM-2020 Satellite Demodulator Revision 4
ASI/RS-422Data Interface MN/SDM2020D.IOM
9–6
Single-ended signals (MF and DF fault signals) are open collector where:
V
oh
=12V max. and V
ol
=0.5V max. @ I
ol
=8 ma.
A pull-up resistor, external to the equipment, is required.
The fault signals, MF and DF, operate as follows: A fault is indicated by an “OFF” (high)
and OK status is indicated by an “ON” (low).
Table 9-2. RS-422 Connector Pinout (Per EIA-530), J5
Pin # Signal Function Name Type Comment
1 530 Shield Shield Mod/Demod
2 Transmit Data (TD-A) BA-A I Modulator
3 Receive Data (RD-A) BB-A O Demodulator
4 Request To Send (RS-A) CA-A I Modulator
5 Clear To Send (CS-A) CB-A O Modulator
6 DCE Ready (DM-A) CC-A O Demodulator
7 Signal Ground AB GND
8 Receive Line Signal Detect (RR-
A)
CF-A O Demodulator
9 Receive Timing (RT-B) DD-B O Demodulator
10 Receive Line Signal Detect (RR-
B)
CF-B O Demodulator
11 Terminal Timing (TT-B) DA-B I Modulator
12 Send Timing (ST-B) DB-B O Modulator
13 Clear To Send (CS-B) CB-B O Modulator
14 Transmit Data (TD-B) BA-B I Modulator
15 Send Timing (ST-A) DB-A O Modulator
16 Receive Data (RD-B) BB-B O Demodulator
17 Receive Timing (RT-A) DD-A O Demodulator
18 N/C
19 Request To Send (RS-B) CA-B I Modulator
20 Not Used
21 Demodulator Fault (DF) DF O Demodulator
22 DCE Ready (DM-B) CC-B O Demodulator
23 Not Used
24 Terminal Timing (TT-A) DA-A I Modulator
25 Modulator Fault (MF) MF O Modulator
9.1.3.3 Receive Output Connectors, J6/J7, BNC, Female
Duplicate signals exit both of these connectors on the demodulator to deliver receive data
to the terrestrial interface. J6 and J7 are both active at all times, and no selection is
required.
