Part Number MN/DST.IOM Revision 2 DSTDigital Satellite Terminal SystemOperator’s Guide

Digital Satellite Terminal System Revision 2 Preface MN/DST.IOM viTables Table 1-1. Specifications...

Digital Satellite Terminal System Revision 2 Preface MN/DST.IOM viiAbout this Manual This manual provides basic installation and operation info

Digital Satellite Terminal System Revision 2 Preface MN/DST.IOM viiiTrademarks Windows is a trademark of Microsoft Corporation. Other product nam

Digital Satellite Terminal System Revision 2 Preface MN/DST.IOM ixELECTRICAL SAFETY The DST Digital Satellite Terminal System has been shown to

Digital Satellite Terminal System Revision 2 Preface MN/DST.IOM xInstallation The installation and connection to the line supply must be made in co

Digital Satellite Terminal System Revision 2 Preface MN/DST.IOM xiEMC (Electromagnetic Compatibility) In accordance with European Directive 89/3

Digital Satellite Terminal System Revision 2 Preface MN/DST.IOM xii• Connections to the transmit and receive IF ports (Type N and Type F, female,

Digital Satellite Terminal System Revision 2 Preface MN/DST.IOM xiiiWarranty Policy This Comtech EF Data product is warranted against defects in

Digital Satellite Terminal System Revision 2 Preface MN/DST.IOM xivNotes: ________________________________________________________________________

1–1 Chapter 1. INTRODUCTION This equipment is designed for maximum reliability and performance in C- and/or Ku-Band applications. 1.1 DST Overview

Digital Satellite Terminal System Revision 2 Introduction MN/DST.IOM 1–2 Fi Figure 1-1. Modem with Typical LNB and a 2 Watt BUC

Digital Satellite Terminal System Revision 2 Introduction MN/DST.IOM 1–3 1.2 Description The DST is an integrated, single thread, Single Channel P

Digital Satellite Terminal System Revision 2 Introduction MN/DST.IOM 1–4 1.2.1 Description of Indoor Unit The IDU for the DST is one of several L

Digital Satellite Terminal System Revision 2 Introduction MN/DST.IOM 1–5 1.3.2 Options The DST includes the following options: How Enabled IDU Op

Digital Satellite Terminal System Revision 2 Introduction MN/DST.IOM 1–6 Notes: __________________________________________________________________

2–1 Chapter 2. INDOOR UNIT INSTALLATION This chapter provides installation and IDU mounting instructions for the DST. 2.1 Unpacking The DST and manu

Digital Satellite Terminal System Revision 2 Installation MN/DST.IOM 2–2 2.2 Equipment Inspection 2.2.1 Included Parts A typical Satellite Terminal

Digital Satellite Terminal System Revision 2 Installation MN/DST.IOM 2–3 2.2.2 Mounting Kit Table 2-2. Optional: Mounting Kit, KT/6228-1 (IDU to R

Digital Satellite Terminal System Revision 2 Installation MN/DST.IOM 2–4 EquipmentRackMountingRail#10 Socket headscrew BRACKETBOLTSSupportBracketIDU

Digital Satellite Terminal System Revision 2 Installation MN/DST.IOM 2–5 2.3.2 IFL Cable Installation CAUTION Comtech EF Data recommends the use

Filename: T_ERRATA 1 Errata A Comtech EF Data Documentation Update Subject: Add Terrasat BUC Mounting Kit, KT/9930-1 Date: November 1, 2005 Docu

Digital Satellite Terminal System Revision 2 Installation MN/DST.IOM 2–6 2.3.3 Cable Installation Note: Prior to connecting the cables, ensure that

Digital Satellite Terminal System Revision 1 Block Up Converter MN/DST.IOM 3–1Chapter 3. BLOCK UP CONVERTER This chapter provides the description

Digital Satellite Terminal System Revision 1 Block Up Converter MN/DST.IOM 3–2 Notes : __________________________________________________________

Digital Satellite Terminal System Revision 1 Block Up Converter MN/DST.IOM 3–3 3.2 LO, Mix and Spectrum Settings 3.2.1 C-Band Table 3-1. LO,

Digital Satellite Terminal System Revision 1 Block Up Converter MN/DST.IOM 3–4 3.2.2 Ku-Band Table 3-2. LO, MIX and Mod Spectrum Settings for Modu

Digital Satellite Terminal System Revision 1 Block Up Converter MN/DST.IOM 3–53.3 BUC Envelope Dimensions and Mounting Notes: 1. Dimensions are

Digital Satellite Terminal System Revision 1 Block Up Converter MN/DST.IOM 3–6 3.4 ODU Installation Refer to Figure 3-2. 1/2-inch Box Wrench (or ad

Digital Satellite Terminal System Revision 1 Block Up Converter MN/DST.IOM 3–7 Table 3-5. Optional: C- and Ku-Band Mounting Kit, KT/9928-1 (BUC to

Digital Satellite Terminal System Revision 1 Block Up Converter MN/DST.IOM 3–8 Table 3-6. Optional: BUC Mounting Kit, KT/10361-1 Item Part No. No

Digital Satellite Terminal System Revision 1 Block Up Converter MN/DST.IOM 3–9 3.5.2 Installation To install the BUC to the antenna: 1. If instal

Filename: T_ERRATA 2 Table 3-1. Optional: BUC Mounting Kit, KT/9930-1 Item Part No. Nomenclature QTY 1 FP/9026-1 Bracket, Lower Block Up 1 2

Digital Satellite Terminal System Revision 1 Block Up Converter MN/DST.IOM 3–10 3.6 Spar Mount 3.6.1 Ku-BUC Spar Mount, Typical NJRC

Digital Satellite Terminal System Revision 1 Block Up Converter MN/DST.IOM 3–11 3.6.2 Ku-Band Spar Mount Typical Terrasant 1. KT/1

Digital Satellite Terminal System Revision 1 Block Up Converter MN/DST.IOM 3–12 3.6.3 C-Band Spar Mount, Typical 1. KT/11124 KIT, B

4–1 Chapter 4. LOW NOISE BLOCK DOWN CONVERTER This chapter provides the description and operation for a LNB. 4.1 Description The LNB amplifies the i

Digital Satellite Terminal System Revision 1 Low Noise Block Converter MN/DST.IOM 4–2 4.1.1 Options Hardware Hardware Hardware Hardware IFL Cable

Digital Satellite Terminal System Revision 1 Low Noise Block Converter MN/DST.IOM 4–34.2 LO, Mix and Spectrum Settings (LNB) 4.2.1 C-Band Table 4-

Digital Satellite Terminal System Revision 1 Low Noise Block Converter MN/DST.IOM 4–44.2.2 Ku-Band Table 4-2. For Ku-Band: LO and MIX Information

Digital Satellite Terminal System Revision 1 Low Noise Block Converter MN/DST.IOM 4–5 4.3 Low Noise Block (LNB) Converter Refer to Figure 4-1 for

Digital Satellite Terminal System Revision 1 Low Noise Block Converter MN/DST.IOM 4–6 5.125(13.02)2.563(6.51)1.563(3.97) Figure 4-2. For Ku-Band :

Digital Satellite Terminal System Revision 1 Low Noise Block Converter MN/DST.IOM 4–7 4.4 LNB Installation 4.4.1 LNB Tooling Refer to Figure 4-1.

Copyright © Comtech EF Data, 2003. All rights reserved. Printed in the USA. Comtech EF Data, 2114 West 7th Street, Tempe, Arizona 85281 USA, 480.

Digital Satellite Terminal System Revision 1 Low Noise Block Converter MN/DST.IOM 4–8 4.4.4 Mounting Kits Table 4-5. Optional: C-Band Waveguide

Digital Satellite Terminal System Revision 1 Low Noise Block Converter MN/DST.IOM 4–9Note: Flat washers maybe omitted if there is interference with

Digital Satellite Terminal System Revision 1 Low Noise Block Converter MN/DST.IOM 4–10 4.5 Cable Installation CAUTION Care should be exercised i

5–1Chapter 5. OPERATION This chapter describes the general operation of the RF terminal using the front panel keys. Detail operation is the same as

Digital Satellite Terminal System Revision 1 Operation MN/DST.IOM 5–2 5.1.2 Initial Power Up – Modem Only Initially, the modem is set up and check

Digital Satellite Terminal System Revision 1 Operation MN/DST.IOM 5–3 5.2 LO, Mix and Spectrum (Inversion) Settings The SDM-300L3 / CiM-300L Sa

Digital Satellite Terminal System Revision 1 Operation MN/DST.IOM 5–4 the satellite, it will be necessary to temporarily match the spectral inversio

Digital Satellite Terminal System Revision 1 Operation MN/DST.IOM 5–5 TX Side Setup: Step No. Selection / Programming Menu Location 13. Disconnect

Digital Satellite Terminal System Revision 1 Operation MN/DST.IOM 5–6 This page is intentionally left blank.

A–1 Appendix A. Selecting LNBs For Use With L-Band Modems This chapter provides guidelines for choosing LNBs for use the DST Terminals. A.1 Introd

Digital Satellite Terminal System Revision 2 Preface MN/DST.IOM iiCustomer Support Contact the Comtech EF Data Customer Support Department for: •

Digital Satellite Terminal System Revision 1 Operation MN/DST.IOM A–2 A.1.2 Carrier Spacing And Frequency Uncertainty When there is no carrier unce

Digital Satellite Terminal System Revision 1 Operation MN/DST-IOM A–3 A.1.3 Frequency Uncertainty Budget An example of a typical frequency uncertai

Digital Satellite Terminal System Revision 1 Operation MN/DST.IOM A–4 The Ku-Band error budget with the 3 ppm LNB was presented earlier, and the bud

Digital Satellite Terminal System Revision 1 Operation MN/DST-IOM A–5 A.1.3.2 Uncertainty for 1 ppm Modem and 0.02 ppm BUC In multi-carrier applica

Digital Satellite Terminal System Revision 1 Operation MN/DST.IOM A–6 Figure A-4. Minimum Symbol Rte versus Satellite Uncertainty For Multi-Carrier

METRIC CONVERSIONS Units of Length Unit Centimeter Inch Foot Yard Mile Meter Kilometer Millimeter 1 centimeter — 0.3937 0.03281

2114 WEST 7TH STREET TEMPE ARIZONA 85281 USA 480 • 333 • 2200 PHONE 480 • 333 • 2161 FAX
