MBT-4000B Multi-Band Transceiver System Revision 1

System Operating Parameters MN/MBT4000B.IOM

4–3

4.5 Block Up Converter Module (BUC-4000) Operating Parameters

The BUC-4000 translates an L-Band output carrier to the desired output frequency (C-, X-, Ku,- or

Ka-Band) with an output level capable of driving a High-Power Amplifier (HPA).

Table 4-1. BUC-4000 C-, X-, Ku-, and Ka-Band Operating Parameters

Band

Frequency

LO Frequency

Inverting

C-Band

5850 to 6650 MHz

4900 MHz

X-Band

7900 to 8400 MHz

6950 MHz

Ku-Band-W

13.75 to 14.50 GHz

12.800 GHz

Ka-Band

30.00 to 31.00 GHz

Notes:

1. No spectral inversion.

2. 10dB gain adjustment.
