OM20 Universal Outdoor Modem Technical Specifications
MN-OM20– Revision 5 8–15
8.13.9 BER Performance (16QAM Turbo)
1E-9
1E-8
1E-7
1E-6
1E-5
1E-4
1E-3
1E-2
1E-1
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Eb/No in dB
BER
Turbo Decoder
Specification
Turbo 3/4
Typical
Performance
16QAM Uncoded Theory
Specification
Turbo 7/8
Figure 8-9. OM20 16QAM BER Performance (Turbo)
